Param Setup
Param Setup is the screen for setting system parameters by application scope. Its title is PARAM MIN/MAX SETUP, and even the same parameter applies to a different target depending on whether it belongs to the JobFile, System Setup, or Master Setup scope. The entry path is System → Param Setup.
The JOB DATA and SETUP DATA buttons at the top switch the scope to edit, and the central
PARAMETER LIST lists that scope's parameters. After editing values, save with SAVE at the bottom,
and use RESTORE to revert to the previous values.
Application scopes
Parameters are divided by application scope as follows. Which scope a value lives in determines "what this value changes with."
| Scope | Applies to | Purpose |
|---|---|---|
| JobFile | Per product / recipe | Values that differ per production item. They change together when the JobFile is switched. See Recipe(JobFile). |
| System Setup | Equipment-common | Values applied commonly to the whole equipment regardless of the item. |
| Master Setup | Upper / administrator scope | The reference upper-level parameters. Handled with administrator permission and not changed casually. |
The key difference: JobFile changes together with the item, System Setup is fixed to the equipment, and Master Setup is the administrative scope that sets the reference above them.
Main areas
The screen consists of the scope-switch buttons at the top, the parameter list in the center, and the save buttons at the bottom.
| Area | Description |
|---|---|
| PARAM MIN/MAX SETUP | The title area. The scope-switch buttons are on the right. |
| JOB DATA / SETUP DATA | Buttons that switch the parameter scope to edit. |
| PARAMETER LIST | The central list where the selected scope's parameters appear. Values are edited directly here. |
| SAVE / RESTORE | Buttons at the bottom. SAVE saves, and RESTORE reverts to the last saved values. |
Workflow
- Open the screen from System → Param Setup.
- Switch the scope to edit with
JOB DATAorSETUP DATAat the top. - Edit the target parameter's value in PARAMETER LIST.
- Save with
SAVEat the bottom. If you edited wrongly, revert withRESTORE. - Place values that should change per item in the JobFile scope and equipment-common values in the System Setup scope to separate their roles.
